Deye 12 kW Hybrid Inverter – Single Phase
Your Smartest Energy Upgrade Starts Here
Looking for a powerful solar inverter that gives you full control of your energy—even during grid failures? Meet the Deye 12 kW Hybrid Inverter – Single Phase: a premium solar hybrid inverter built to handle large loads, manage multiple energy sources, and give you reliable, efficient power all day, every day.
Whether you live in a city, run a rural business, manage a school, or just want to keep your home powered without interruptions, the Deye 12 kW Hybrid Inverter – Single Phase gives you the performance and features of a professional-grade system—with the flexibility and simplicity anyone can understand.
⚡ What Is the Deye 12 kW Hybrid Inverter – Single Phase?
The Deye 12 kW Hybrid Inverter – Single Phase is a single-phase, high-capacity solar inverter (Model: SUN-12K-SG01LP1-EU) that combines power from solar panels, batteries, the grid, and even a diesel generator into one intelligent control system. It stores excess solar power in batteries, powers your home or business directly, and automatically switches between sources to keep your lights on and bills low.
It is one of the most advanced and versatile hybrid inverters in Kenya and around the world.
🔋 Battery Charging and Storage Made Easy
| Feature | Specification |
|---|---|
| Battery Type | Lithium-ion / Lead-acid |
| Voltage Range | 40 – 60 V |
| Charging Current | Max 220A |
| Discharging Current | Max 220A |
| Battery Inputs | 2 |
| Smart Charging | Auto-adapts to lithium BMS |
This inverter charges fast. With up to 220 amps of charge/discharge current, your batteries fill quickly, and energy is ready for night use or backup. Whether you’re using a lithium battery or a lead-acid bank, the Deye 12 kW Hybrid Inverter – Single Phase will manage it efficiently.
☀️ Solar Power Like Never Before
| Feature | Specification |
|---|---|
| Max PV Input Power | 24,000 W |
| Max Input Voltage | 500 V |
| Start-up Voltage | 125 V |
| MPPT Voltage Range | 150 – 425 V |
| Rated PV Input Voltage | 370 V |
| Operating Current | 26 + 26 + 26 A |
| Short-Circuit Current | 44 + 44 + 44 A |
| No. of MPPT Trackers | 3 |
| Strings per Tracker | 2 + 2 + 2 |
You can connect a whopping 24kW worth of solar panels to this inverter—perfect for powering large homes, farms, or businesses. With 3 MPPT trackers, the system ensures solar energy is captured efficiently even if panels face different directions.
🔌 AC Power Output That Handles Heavy Loads
| Feature | Specification |
|---|---|
| Rated Output Power | 12,000 W |
| Max Apparent Power | 13,200 VA |
| Rated Output Current | 54.5 / 52.2 A |
| Max Output Current | 60 / 57.4 A |
| Continuous AC Passthrough | 100 A |
| Peak Off-Grid Output (10s) | 24,000 W |
| Power Factor Range | 0.8 leading to 0.8 lagging |
| Grid Voltage | 220V / 230V |
| Grid Frequency | 50Hz / 60Hz |
| Grid Connection Type | L + N + PE |
This means you can run your entire home, workshop, or institution with one inverter. Even during high demand—like water pumping, welding, or simultaneous appliance use—it holds steady.
💡 Why Choose the Deye 12 kW Hybrid Inverter – Single Phase?
✅ Built for On-Grid & Off-Grid Life
Operate in grid-connected, off-grid, or hybrid modes. When the power goes out, your inverter takes over instantly. When the sun shines, it saves you money.
✅ Scalable Power
Need more than 12 kW? No problem. Connect up to 16 inverters in parallel for both off-grid and on-grid expansion. Perfect for schools, estates, or solar farms.
✅ Schedule Your Energy
With 6 programmable time periods per day, you control when the system charges batteries or draws from them—perfect for time-of-use tariffs.
✅ Diesel Generator Support
Already have a generator? Use it for backup charging or hybrid operation. The Deye 12 kW Hybrid Inverter – Single Phase handles it seamlessly.
📈 Efficiency, Performance & Safety
| Feature | Specification |
|---|---|
| Max Efficiency | 97.6% |
| Euro Efficiency | 96.5% |
| MPPT Efficiency | >99% |
| THDi (Distortion) | <3% |
| DC Injection Current | <0.5% of nominal |
That means nearly all the energy from your solar panels is converted to usable power—not lost as heat or noise.
🛡️ Total Protection Built-In
| Protection Features | ✓ |
|---|---|
| Reverse DC Polarity | ✅ |
| Overcurrent & Overvoltage | ✅ |
| AC Short Circuit | ✅ |
| Thermal Shutdown | ✅ |
| Arc Fault Interruption (AFCI – Optional) | ✅ |
| Anti-Islanding | ✅ |
| Residual Current (RCD) Detection | ✅ |
| Insulation Monitoring | ✅ |
| DC/AC Surge Protection (Type II) | ✅ |
Your home and your equipment are safe under all conditions.
🌍 Ready for Harsh Environments
| Feature | Value |
|---|---|
| IP Rating | IP65 |
| Operating Temp | -40°C to +60°C |
| Humidity | 0–100% |
| Altitude Tolerance | ≤ 2000m |
| Cooling Type | Intelligent air cooling |
| Noise Level | <50 dB |
The Deye 12 kW Hybrid Inverter – Single Phase is designed for real African conditions—dust, heat, and unpredictable weather included.
📡 Communication & Monitoring
Keep an eye on your power—anytime, anywhere.
| Feature | Details |
|---|---|
| Monitoring Modes | WiFi / GPRS / 4G / Bluetooth / LAN |
| Communication Ports | RS485 / RS232 / CAN |
Use a mobile app or connect it to your smart energy dashboard.
📦 Size, Weight & Warranty
| Feature | Specification |
|---|---|
| Size (W×H×D) | 464 × 763 × 282 mm |
| Weight | 52 kg |
| Warranty | 5–10 years (location-based) |
View or download Deye 12kW Hybrid Inverter – single phase datasheet
or Manual
🇰🇪 Perfect for Kenya’s Energy Challenges
Kenya faces high grid power costs and unreliable supply in many areas. The Deye 12 kW Hybrid Inverter – Single Phase is the ultimate solution for:
-
Homes that want to slash electricity bills
-
Businesses that need backup to avoid losses
-
Farms and rural facilities off the national grid
-
Institutions that need clean, 24/7 power
Use solar during the day, batteries at night, and the grid only when needed. The system switches intelligently, so you never run out of power.
🛒 Get the Deye 12 kW Hybrid Inverter – Single Phase Today
Want clean, constant energy? Want freedom from rising electricity bills? Want to never worry about blackouts again?
Then it’s time to choose the Deye 12 kW Hybrid Inverter – Single Phase.
Contact us today to:
-
Get the best Deye 12 kW Hybrid Inverter – Single Phase price in Kenya
-
Book professional installation and battery sizing
-
Get expert advice on solar system design
🔑 Final Thoughts: Power That Works For You
The Deye 12 kW Hybrid Inverter – Single Phase gives you full control of your power—clean energy when the sun shines, stored power when it doesn’t, and automatic switching when you need it most. It’s smart, strong, and made for today’s energy needs.
Make the switch. Empower your home. Upgrade to Deye.
