Hober 2.2kW Solar Pumping Inverter – Model HSPH2200L(Single – Phase but Three-Phase Compatible)
The Hober 2.2kW – HSPH2200L – is a highly adaptable solar pumping inverter engineered for optimal performance with 220/240V AC pumps. This model efficiently converts DC power from your solar array into stable AC power, making it suitable for both single-phase and compatible three-phase pumps. With its advanced MPPT technology, seamless hybrid operation with AC grid or generator backup, and robust IP65 protection, the HSPH2200L ensures a consistent and reliable water supply for residential, agricultural, and light commercial applications, maximizing the return on your solar investment.
Hober 2.2kW Key Features & Benefits (HSPH2200L Specifics)
The Hober 2.2kW – HSPH2200L – is precisely Optimized for 220/240V Systems, delivering a maximum output power of 2200W (3 HP) at 220/240V.1 This makes it an ideal choice for the prevalent single-phase and compatible three-phase AC pumps found in many residential and light commercial settings.
This inverter offers Wide Solar Input Flexibility, accommodating a broad DC input voltage range. It supports a minimum Vmp (Maximum Power Voltage) of 200V and a maximum Voc (Open Circuit Voltage) of 450V. For solar-only input, the recommended Vmp range is 300Vmp to 430Voc, while for hybrid power input, it is 340Vmp to 400Voc.1 It is important to note that the HSPH2200L does not feature an internal booster.1 This design choice means the inverter is optimized for direct connection to solar arrays that can naturally achieve these higher voltage ranges, potentially contributing to its efficiency at higher voltages and streamlining its internal architecture for applications where larger arrays are expected.
For uninterrupted operation, the HSPH2200L provides Seamless Hybrid Operation. It accepts a 220/240V single-phase AC input with a rated current of 15A.1 This intelligent feature ensures that the system automatically supplements power from the grid or a generator when solar input is low, guaranteeing continuous water availability even during periods of insufficient sunlight.
The inverter’s Robust & Quiet Operation is a key advantage. Encased in an IP65 waterproof and dustproof enclosure, it offers superior protection for outdoor installations.1 Furthermore, it incorporates a force cooling fan with an IP68 rating.1 This higher IP rating for the fan—a critical moving component—demonstrates meticulous engineering to protect it against continuous immersion, significantly enhancing the inverter’s overall durability and reliability by safeguarding its most vulnerable part from environmental stressors. Despite its powerful cooling capabilities, the HSPH2200L operates quietly, with noise levels below 50dB.1
For user convenience, the HSPH2200L features Intuitive Monitoring. A clear 128×64 LCD display provides real-time operational data at a glance, making local system status checks straightforward.1 For enhanced control and convenience, optional 4G/Wifi monitoring and control capabilities are available, allowing remote management of the pumping system via a mobile app or computer.1
Detailed Technical Specifications Table: Hober HSPH2200L
This comprehensive table provides a quick, at-a-glance reference for all critical technical parameters of the Hober HSPH2200L. It allows potential buyers to easily verify compatibility with their existing pump systems and solar arrays, serving as a primary source of factual data for informed purchasing decisions. This structured presentation facilitates direct comparison with other products or verification against user requirements, enhancing transparency and user experience on an e-commerce platform.
Feature | Specification (HSPH2200L) |
Solar Input | |
Max Voc Voltage | 450V |
Min Vmp Voltage | 200V |
Recommend Vmp Voltage | 300Vmp<DC Input<430Voc (Only Solar) / 340Vmp<DC Input<400Voc (Hybrid) |
Max MPPT Efficiency | 99% |
Max Input Current | 11A |
Number Of Strings | 1 |
Inside Booster | No |
Hybrid AC Input | |
Voltage | 220/240V 1-Phase |
Rated Input Current | 15A |
Hybrid Mode | Automatic AC supplement/disconnect |
AC Output For Pump | |
Max Adapted AC Pump HP | 3 HP |
Max Adapted AC Pump Power | 2200W |
Phase | Single Phase (1 phase) / 3Phase (Compatible) |
Max Output Voltage | 220/240 V |
Max Output Frequency | 50-60 Hz |
Rated Output Current | 16 A |
Other Characteristics | |
Max Efficiency | 97% |
Water Level Sensor | Yes (well / tank) |
4G/Wifi Monitor&Controller | Support (Optional) |
Display | LCD Display (128*64) |
Waterproof | IP65 |
Noise | < 50dB |
Cooling Method | Force Cooling by Fan (IP68) |
Protection | Solar DC input Low/Over Voltage, Reverse Polarity, Over Flow of Tank, Against Lightning, AC input/Output Phase Lost, Dry-Run, AC Output Short-circuit, Over Current, Over Temperature, Over Load 1 |
Operating Environment | |
Temperature | -10 to 60°C (derate above 60°C) |
Max Humidity | 95%RH |
Using Altitude | < 3000m (derate above 3000m) |
Package | |
Size (LWH) | 400310200mm |
Weight | 6KG |
Ideal Applications Hober 2.2kW (HSPH2200L):
The Hober Hober 2.2kW -HSPH2200L- is ideally suited for a variety of applications requiring reliable 220/240V AC power for water pumping:
- Residential Water Supply: Perfect for homes and small farms needing consistent water for daily use.
- Small-Scale Irrigation Systems: Efficiently powers pumps for gardens, small agricultural plots, or greenhouses.
- Water Transfer: Effectively moves water for tanks and boreholes utilizing 220/240V single-phase pumps.
Off-Grid Properties: Provides reliable water access for remote cabins or properties where grid power is unreliable or unavailable, especially with its AC backup capability.
